TB.250 EGG-LAYING CUBSTONE MAKING MACHINE STRIPS CURBS ON CONCRETE FLOO
A machine featuring high production efficiency, distinctively easy and effortless to operate. The excellent quality of compression together with a fast production cycle enables a smooth, evenly crafted and considerable output of cement curbstones, TB.250 is very strongly built and rugged; its mechanical parts and hydraulic elements exceeding necessities guarantee long life and extreme reliability. Quality production, minimum service and maintenance needs together with rugged; strong built make it the safe choice for the most demanding producers.
SPECIFICATIONS
Weight & Dimension: 3100 kg, 2.30 x 2.35 x 2.30 m
Power: 220-380V; 3 Phases
Motors: 3 motors tot 10 kW
Semiautomatic machine with loading bucket
First quality hydraulic system with adjustable pressure
5 Control levers for: 1. Mould loading 2. Compression 3. Stripping 4. Steering 5. Turning
Low tension remote control
Mixing bucket with capacity of 650L with automatic opening and closure
Special torsion built-in bar to ensure constantly parallel stripping
3 Phases Control Panel to operate & protect the components.
Changeable mould
Production Rate: 200-250 curbs/h
